Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Accuracy | ±10% ppm |
| Application | Count total machine usage hours, tools usage time |
| Approvals | CSA Certified, IP65, NEMA-4, UL Recognized |
| Connection Type | Screw Terminal |
| Cut Out, Panel | 45×22 mm |
| Depth | 0.157" (4mm) |
| Dimensions | 44.9mm L x 21.9mm H |
| Dimensions, Cutout, Inches | 45 x 22 mm |
| Display Digit Height | 7 mm |
| Display Type | Digital, LCD |
| Function | Timer |
| Input Type | Contact Closure, Open Collector |
| Minimum Operating Temperature | -10 °C |
| Mounting Type | Panel, DIN |
| Number of Digits | 7 Digits |
| Primary Type | Electronic |
| Product Header | 7999 Mite Elapsed Timer |
| Series | |
| Supply Voltage | 5 to 240 V ac⁄dc VAC/VDC |
| Temperature Range | -10 to 60 °C |
| Temperature, Opening, Maximum | 60 °C |
| Type | Electronic |
Overview
Low-cost family of compact totalizers, elapsed-time-indicators, and rate indicators with totalizer. Easy-to-read 8 mm high LCD display. Unidirectional totalizers and timer models are self-powered by a long-life lithium battery. Fast panel mounting into a 1" × 2" cut-out. NEMA-4 rated; CSA certified, UL recognized.
